ZADIM from Sweden offers two core product families

screw-driven lift(Z5000 / Z6000 / Z7000) and steel-belt traction (Z8000 / Z9000 / Z9100). The Z6000 is fully manufactured in Sweden. Z5000, Z7000, Z8000, Z9000 and Z9100 are produced on domestic standardised production lines. All models come factory-fitted with an integrated panoramic shaft featuring Nordic-inspired aesthetics. Below is a reference covering served floors, minimum external opening dimensions, rated payload, pit-depth requirements and top-headroom height. On-site measurements by ZADIM qualified engineers shall prevail in real-world projects.

1. Screw-driven range - ideal for retrofits into finished homes, mechanical self-locking safety

Z5000 / Z5100 Enjoy Series (Domestic production)

• Served floors: 2-3-storey duplex / upper-level townhouse units

• Minimum external opening: Z5100 down to 860 × 860 mm

• Rated payload: 160-230 kg (2-3 passengers). Ultra-compact footprint mainly for individual passenger use.

• Pit requirement: 50-70 mm. Can sit directly on finished floor with custom ramp solution.

• Minimum top-headroom: 2400 mm

• Doors: Automatic swing-open doors as standard; upgradeable to automatic glass doors.

• Best-fit scenarios: Tight-space retrofits, narrow stair voids, post-fit into fully-finished villas. Note: cabin interior is compact at minimum size; increase opening dimensions if wheelchair access is required.

• Full-turnkey budget reference: £26 400-£31 200

Z6000 Swedish-origin complete-unit screw-driven series

• Served floors: 2-4-storey detached / semi-detached villas

• Minimum external opening: 860 × 860 mm - Rated payload: 400-500 kg, wheelchair-accessible

• Pit requirement: 50 mm. Direct floor-mount installation with ramp feasible. - Minimum top-headroom: 2400 mm

• Safety highlights: Complete Swedish manufacture, mechanical self-locking, full EN 81-41 European certification, 10-year dedicated warranty on screw-nut transmission assembly.

• Best-fit scenarios: Customers seeking original Swedish build-quality, households with elderly or wheelchair users, older-villa retrofits.

• Full-turnkey budget reference: £33 600-£45 600

Z7000 Screw-driven (Domestic production)

• Served floors: 2-4-storey villas

• Minimum external opening: 900 × 900 mm

• Rated payload: 260-400 kg, wheelchair-accessible

• Pit requirement: 50 mm - Minimum top-headroom: 2400 mm

• Best-fit scenarios: Customers wanting screw-drive safety characteristics with more spacious cabin and better cost-efficiency versus imported Z6000.

• Full-turnkey budget reference: £28 800-£33 600

2. Steel-belt traction panoramic range - ideal for new-build homes and high-frequency daily use, smooth & quiet operation

Z8000 / Z8100 Classic Steel-belt Series (Domestic production)

• Served floors: 2-5-storey villas - Minimum external opening: 960 × 910 mm

• Rated payload: 160-320 kg (2-4 passengers). Multiple cabin-size options available.

• Minimum pit depth: 130 mm (optimised shallow-pit for domestic use)

• Minimum top-headroom: 2550 mm

• Doors: Automatic swing-open doors; optional automatic panoramic glass doors. Integrated shaft supports 3-sided or 4-sided panoramic layouts.

• Best-fit scenarios: New-build projects, high-frequency family daily use, preference for smooth quiet ride, wheelchair-access requirement.

• Full-turnkey budget reference: £30 000-£39 600

Z9000 / Z9100 Premium Luxury Steel-belt Series (Domestic production)

• Served floors: 2-6-storey large detached villas

• Minimum external opening: 960 × 910 mm

• Rated payload: 160-320 kg. Fully customisable interior finishes including leather panels, star-effect ceiling and ambient lighting. Z9100 features upgraded high-end car-operating panel.

• Minimum pit depth: 130 mm

• Minimum top-headroom: 2550 mm

• Best-fit scenarios: 4-6-storey large private residences, full 4-sided panoramic glass shaft, luxury minimalist / light-luxury custom interiors.

• Full-turnkey budget reference: £38 400-£52 800

Z3000 Elite Series

Z2000 Minimalist Series

Quick selection guide

1. Finished-property retrofit, no deep-pit excavation possible, footprint under 1 m², 2-3 floors → Z5100 / Z6000. For wheelchair access prioritise Z6000 / Z7000.

2. Seeking fully-imported Swedish unit and mechanical self-locking safety → Z6000.

3. New-build property, high-frequency usage, 2-5 floors, smooth quiet panoramic ride → Z8000.

4. 4-6-storey large detached villa, premium custom interiors, full 4-sided panoramic view → Z9000 / Z9100.

Important purchasing notes

1. Published minimum external opening dimensions include shaft frame and do not represent clear cabin internal size. 860 × 860 mm is an extreme-limit case. Increase opening size where columns or wall projections exist.

2. Pit-depth values are theoretical factory data. Actual feasibility depends on on-site assessment of under-floor pipework and waterproof membranes. Where excavation is impossible, use floor-mount installation plus custom ramp.

3. Higher payload, more served floors, additional panoramic sides and custom-interior options (star-effect ceiling, ambient lighting, special glass) will increase total cost.

4. Above 4 served floors, screw-driven unit costs rise significantly; steel-belt traction models are preferred.

5. All budget figures are full-turnkey reference values (lift unit + factory-integrated shaft + standard transport, installation and commissioning). Floor-excavation, waterproof reinstatement and custom ramps are extra-cost items. Final formal quotation is issued after ZADIM on-site survey.

When selecting a model, prioritise building-site civil-work constraints first, then floor count, passenger-access requirements, and finally budget. Do not rely solely on payload figures; on-site survey is mandatory to confirm project feasibility.
